| Material type | Metal |
|---|
| Material name | Aluminum 5083-H111, AlMg4,5Mn0,7 , 3.3547 |
|---|
| Process compatibility | CNC machining |
|---|
| Mechanical properties, Ultimate tensile strength | 270 - 350 MPa |
|---|
| Yield strength | 110 - 160 MPa |
|---|
| Young's modulus (modulus of elasticity) | 68 - 72 GPa |
|---|
| Elongation at break | 13 % |
|---|
| Hardness | 74 HV |
|---|
| Physical properties, Corrosion resistance | Excellent |
|---|
| Magnetism | Non-magnetic |
|---|
| Weldability | High |
|---|
| Thermal properties, Maximum service temperature | 80 - 100 °C |
|---|
| Thermal expansion coefficient | 24 - 25 10^-6/ºC |
|---|
| Thermal conductivity | 118 - 128 W/(m⋅°C) |
|---|
| Electrical properties, Electrical resistivity | 5,85 - 6,05 μΩ*cm |
|---|
| ESD Safety | No |
|---|
| Post treatments, Post-Processing | Annealing & Cold working |
|---|
| Anodizing compatibility | Suitable |
|---|
Aluminum 5083-H111 | 3.3547 | AlMg4.5Mn0.7
Aluminum 5083 (CNC) is a strain hardening aluminum alloy with excellent corrosion resistance. Suitable for marine applications. Can be welded.
Metal Chemical resistant Non-magnetic
| Common applications | Marine industry, Railroad cars, Vehicle bodies, Pressure vessels |
|---|
