| Material type | Metal |
|---|
| Material name | Aluminum 5052, AlMg2,5 , 3.3523 |
|---|
| Process compatibility | CNC machining |
|---|
| Mechanical properties, Ultimate tensile strength | 190 - 320 MPa |
|---|
| Yield strength | 75 - 280 MPa |
|---|
| Young's modulus (modulus of elasticity) | 68 - 71 GPa |
|---|
| Elongation at break | 2 - 22 % |
|---|
| Hardness | 46 - 83 HB |
|---|
| Physical properties, Corrosion resistance | Good |
|---|
| Magnetism | Non-magnetic |
|---|
| Thermal properties, Maximum service temperature | 190 °C |
|---|
| Thermal expansion coefficient | 23.8 - 25.7 10^-6/ºC |
|---|
| Thermal conductivity | 138 - 140 W/(m⋅°C) |
|---|
| Electrical properties, Electrical resistivity | 4.99 μΩ*cm |
|---|
| Post treatments, Post-Processing | Hot & Cold working, Hardening only by cold working |
|---|
| Anodizing compatibility | Suitable |
|---|
Aluminum 5052 | AlMg2,5
Aluminum 5052 is a strain hardening aluminum alloy with excellent corrosion resistance. Suitable for marine applications. Can be welded.
Metal
| Common applications | Hydraulic tubes, Kitchen appliances, Cabinets, Small boats, Home freezers, Aircraft tubes, Fencing |
|---|
