| Material type | Metal |
|---|---|
| Material name | Aluminum 2017, AlCu4MgSi, 3.1325 |
| Process compatibility | CNC machining |
| Mechanical properties, Ultimate tensile strength | 190 - 430 MPa |
| Yield strength | 76 - 280 MPa |
| Young's modulus (modulus of elasticity) | 71 - 73 GPa |
| Elongation at break | 14 - 22 % |
| Hardness | 80 - 110 HB |
| Physical properties, Corrosion resistance | Fair |
| Magnetism | Non-magnetic |
| Weldability | Good |
| Thermal properties, Maximum service temperature | 190 °C |
| Thermal expansion coefficient | 23.6 - 25.4 10^-6/ºC |
| Thermal conductivity | 134 - 150 W/(m⋅°C) |
| Electrical properties, Electrical resistivity | 5.15 μΩ*cm |
| Post treatments, Post-Processing | Annealing, Aging |
| Anodizing compatibility | Suitable |
| Common applications | Screw machine products and fittings, Pulleys and gauges, Rivets, General structural components, Fasteners, Aircraft components |
|---|
