Product Description

The TECHNO Magical Automatic Feeder is a next-generation pneumatic feeder designed to simplify and automate material handling. With no moving parts, it is exceptionally safe, quiet, energy-efficient, and maintenance-free. Powered by compressed air, this compact solution requires no electricity and supports adjustable airflow for a wide range of applications.

Capable of transporting up to 1000 kg/hour, this feeder excels in long-distance operations and connects easily to standard hoses. Whether it’s caps, tablets, screws, or plastic pellets, this feeder delivers seamless and hygienic conveying in industrial settings.

Key Features:

   - No moving parts: Safe and maintenance-free.
   - Compact structure, small size, easy operation, and long lifespan.
   - Powered by compressed air, no electricity required.
   - Adjustable airflow, low noise, and energy-efficient.
   - Supports long-distance transmission with standard hose connections.
   - High flow capacity, capable of transporting up to 1000 kg per hour.

Technical Specifications:

   - Air Pressure: >0.6Mpa
   - Air Flow: >0.03m³/min
   - Compressor Power: ≥7.5KW
   - Interface Details:
     - Feed Inlet (Suction Port)
     - Compressed Air Inlet (12mm diameter)
     - Discharge Hole (Discharge port, 28mm inner diameter)

Additional Notes:

- The company emphasizes simplicity, automation, safety, efficiency, and cost-effectiveness in its products.
- The pneumatic feeder is highlighted as revolutionary for material handling, offering convenience and reliability.

Additional Information

• Uses:

  • Bottling Lines: Transporting caps and small parts

  • Food Industry: Dry food movement

  • Pharma: Conveying pills, capsules, and tablets

  • Manufacturing: Screws, plastic pellets, and small metal parts

  • Waste Handling: Lightweight scrap in packaging, textiles, and printing
