Five-position external Geneva drive

TECHNO CNC presents the Five-Position External Geneva Drive, a high-precision indexing mechanism designed for intermittent motion applications. The Geneva drive, widely used in automation, packaging, robotics, and mechanical indexing systems, enables accurate and controlled movement with minimal wear and high efficiency.

This external Geneva drive operates through a rotating driver wheel with a driving pin, which engages with the slots of the Geneva wheel, ensuring precise stop-and-go motion with five distinct positions. Designed with durability, reliability, and high-speed performance in mind, this system is an ideal solution for automated manufacturing and conveyor indexing applications.

Key Features:

Precise 5-Position Indexing – Ensures accurate and repeatable motion control
Smooth & Low-Vibration Operation – Minimizes mechanical stress and improves efficiency
High-Strength Material Construction – Engineered for long life and consistent performance
Minimal Maintenance – Low-friction design for reduced wear and extended durability
Customizable Sizes & Configurations – Available in multiple material and motion range options
Industrial-Grade Performance – Suitable for automation, robotics, and mechanical engineering applications
